Image4K

Full 4K high bandwidth graphics card
Designed for professional, multi-screen and video wall installations, Image4K is a very powerful graphics card, enabling scalable solutions and offering full 4K60 4: 4: 4 content on four HDMI 2.0 outputs.

Fully integrated into Datapath graphical configuration wizard, Image4K is easy to configure for different combinations of LED monitors, projectors or controllers. Output resolution, rotation and wall layout are easily configured via the intuitive graphical interface in minutes.

Software driver
Equipped with a highly optimized driver to work efficiently with Datapath hardware available for Windows 10, 11 e Windows Server 2019 installations. The function of the display driver is to present a large desktop to the Windows operating system. The multi-display driver supports up to 24 screens.

WallControl 10 software
Image4K is fully compatible with Datapath WallControl 10 software that allows you to simply launch and position video and application windows to create complex video wall layout configurations. WallControl 10 offers a representative window of the entire display wall showing the position and size of each window, including a live preview of all video content. With the full version you can save layouts and recall them for future use and use WallControl 10 on a remote PC via a network connection.

Main features:
- Card format: PCI Express x16 Mechanical, x8 Electrical (Gen. 3)
- Board size: 110mm x 177mm (including heatsink)
- Maximum output resolution: 3840 x 2160 at 60Hz (max 594 MP / s) for each channel
- Maximum color depth: 8-bit per component
- Maximum number of cards per system: 6 (24 display channels)
- Graphics card memory: 8GB
- Maximum current at + 3.3V: 0.6A
- Maximum current at + 12V: 4.0A
- Maximum thermal power: 50W
- Operating temperature: from 0 ° C to 35 ° C
- Storage temperature: -20 ° C to 70 ° C
- Relative humidity: from 5% to 90% non-condensing
- MTBF: over 80,000 hours
